The Productivity Paradox

 And The Promise Of Automated Configuration
Chris Irwin
Chris Irwin
VP Sales EMEA, Asia
J2 Innovations

Articles
Interviews
Releases
New Products
Reviews
[an error occurred while processing this directive]
Editorial
Events
Sponsors
Site Search
Newsletters
[an error occurred while processing this directive]
Archives
Past Issues
Home
Editors
eDucation
[an error occurred while processing this directive]
Training
Links
Software
Subscribe
[an error occurred while processing this directive]

Nearly every building’s HVAC controls are different; even retail chains, whose formula for new shops typically requires the same fit-out equipment and services, typically find that the local building’s shape, size, and condition makes each implementation different. This reality has meant that building automation systems manufacturers have had to ensure their systems are very configurable to meet the diversity required.

Automation

The downside of this approach has been the complexity of the engineering process. Whilst systems have become easier to program over the years; they still require plenty of time, and, on big projects, there is a considerable amount of repetitive work to achieve the required configuration. There have been many attempts to standardise on the control logic and graphics required. However, in most market applications, these have met with limited success, since they typically constrain the way in which the equipment is controlled, reducing system flexibility.

As far as Building Management Systems (BMS) are concerned, we can see a trend towards controlling more than just the HVAC. Integrated systems now also control lighting, blinds, and link to fire, security and other systems. The result is an increased level of complexity that has given rise to software that can be programmed to do almost anything and, conversely, a shortage of skilled engineers needed to undertake the programming.

Whilst the cost of the BAS hardware and BMS software has been reduced in real terms, the total cost of the installed project has not. This is fine for the wages of those BAS engineers who do have the skills; however, the productivity of controls engineers is becoming ever more important.

Most manufacturers have addressed this challenge by offering standard libraries of graphics and control logic. But, as their system software is designed to be programmed with each data point individually assigned, much manual configuration is still required. An alternative approach is to automate the links by smarter use of metadata or tags. By creating an abstracted data model with all the data tagged with its context, the system can, to a large extent, build itself, removing huge chunks of manual configuration. There are further gains to be had in automating the previously very tedious task of commissioning automation systems. Again, the use of tagging creates a new possibility – automated sequences applied across the site auto-generating reports that will identify system defects. Further engineering time savings can also be achieved in the maintenance of the site as tagging greatly facilitates the deployment of automated fault detection diagnostics (FDD).

The problem for most BMS manufacturers is that their software was architected and designed before the concepts and benefits of data modelling and tagging were well understood. They will need to fundamentally redesign their software to achieve this way of automation configuration, commissioning and analytics.

In contrast, FIN Framework technology from J2 Innovations offers this level of automated configuration, enabling complex integrated systems to be implemented with a much lower overhead in terms of engineering time. This is why we refer to FIN Framework as the “next-generation software platform for the building automation and the IoT.”

The benefits can be illustrated by FIN’s automated Point Graphics, which require zero manual configuration but provide full access to the live and historical data as well as overrides and schedules. For customised graphics, FIN largely automates the creation process dramatically, compared to conventional BMS software.

Alarming is another function that benefits hugely from tagging. FIN’s smart alarms use control logic to enable the easy creation of sophisticated routines, which can be applied site-wide using the data tags, instead of the old way of adding alarm thresholds in every point.

[an error occurred while processing this directive]Automated configuration, therefore, delivers on the promise of reduced engineering time and cost, with easier multi-system integration achieved by standardising the tagging of data. Previous attempts to standardise control logic and graphics have driven a trend towards packaged pre-configured and pre-tested equipment controllers. Unfortunately, the pre-packaged logic and graphics limit innovation and flexibility and do not solve the problem of systems with diverse needs. With standardised tagging and data modelling, much more can be achieved efficiently and cost-effectively.

BMS engineers can embrace this future of more automated system configuration because the demands for greater functionality seem set to grow further as businesses find more ways to make buildings smarter. What will happen is that the BMS engineer’s role will shift. Their work will become more interesting – with less time spent on boring and repetitive configuration tasks, and more opportunity working with system-level integration and data processing aspects.

For building owners and operators, the advent of automated system configuration leveraging data tagging delivers on the prospect of building controls installations that are simpler and less expensive to install and manage.

Watch this space as the industry adapts to the importance of tagging, and the significant changes it will bring.

More information is available at www.j2inn.com.

Editors notes
J2 Innovations is a fast-growing, innovative software development company based in California that created FIN Framework, which is a state-of-the-art open framework for building automation and IoT applications. Responding to the market demand for easier to configure and use solutions for managing buildings and IoT applications, the J2 Innovations team has been laser-focused on usability and automating what were previously labour-intensive engineering tasks.

Issued by Wildwood PR on behalf of J2 Innovation
For further information, please contact Wildwood PR at: jeff.hayward@wildwoodpr.com
